Aloris Universal Tool Holder No. 22 – DA-22
- A unique design provides for many angular turning, contouring and chamfering operations.
- The cartridge has 12 indexing positions at 15° intervals.
- All holders assure proper cutting edge and clearance angles at all indexing points.
- Two-way adjustable rake for right or left hand turning with 5° cutting angle – positive stop.
- Tool steel cartridge adjusts every 15º for right or left hand turning, facing or chamfering.
- 12 positive lock positions.
- Exclusive positive lock with 2-way force holding insert down and tight against shoulder.
- Standard triangular carbide insert has 6 cutting edges.
The model 22, with its two-dovetail design, leads to a wide range of applications by permitting front and rear turning, contouring, boring and facing operations.
Dimensions (see image):
A: 2-3/4″
E: 2″
Min. Bore Dim.: 4-1/4″
Max Bore Length: 3-1/2″
